Kubota excavators are all powered by Kubota Tier 4 emission engines. The modern engine design maximizes digging and lifting performance, delivers minimized noise and vibration and meets the latest engine emission regulation.
All Kubota excavators have a two speed drive that allows for efficient machine maneuverability and backfill operations.
- Front pin bushings to help maximize durability
- Centralized swivel bearing lubrication
- Protected cylinder hoses
- Steel hood panels
- One-sided engine maintenance
- Wide hood openings for easy access to engine and other vital components
| Engine | |
|---|---|
| Model: | Kubota V2607-CR-TE4 |
| Horsepower (gross): | 68.3 |
| Displacement (cu. in.) | 159.6 (2615) |
| Dimensions | |
|---|---|
| Overall Length, ft (mm): | 136.4 (3465) |
| Overall Height, ft (mm): | 118.5 (3010) |
| Overall Width, ft (mm): | 65.2 (1657) / 67.6 (1717) |
| Hydraulics | |
|---|---|
| Pump Capacity (GPM): | |
| Auxiliary Hydraulic Flow (GPM): | 17.4 (65.8) / 27.0 (102.2) |
| Max. Breakout Force (lbs): | 4614 (2093) |
| Drive System | |
|---|---|
| Travel Speed (low/high) | 4.9 mph (7.9 km/h)/7.1 (11.5) |
| Tumbler Distance ft. in. (mm) | |
| Crawler Length ft. in. (mm): | |
