Kubota KX030-4
MSRP AS LOW AS:
Regular price
$50,369.00 USD
Payments as Low as $766/Month.
The KX030-4 with 24.7 horsepower gets the job done where larger excavators can't maneuver. Powerful breakout forces combined with the ability to simultaneously operate the pilot controlled hydraulic functions make the work day more productive. Kubota is the world’s #1 selling compact excavator for 20 years.*
*According to 2023 data from Off-Highway Research including all Kubota Group brand sales.
Images may reflect a higher MSRP.
Clean Running Kubota Tier 4 Engine
Kubota excavators are all powered by Kubota Tier 4 emission engines. The modern engine design maximizes digging and lifting performance, delivers minimized noise and vibration and meets the latest engine emission regulation.
Two Speed Travel
All Kubota excavators have a two speed drive that allows for efficient machine maneuverability and backfill operations.
Serviceability
- Front pin bushings to help maximize durability
- Centralized swivel bearing lubrication
- Protected cylinder hoses
- Steel hood panels
- One-sided engine maintenance
- Wide hood openings for easy access to engine and other vital components
Engine
| Engine | |
|---|---|
| Model: | Kubota KX030-4 |
| Horsepower (gross): | 24.7 |
| Displacement (cu. in.) | |
Dimensions
| Dimensions | |
|---|---|
| Overall Length, ft (mm): | 15'1.1" (4600) |
| Overall Height, ft (mm): | 7'11" (2420) |
| Overall Width, ft (mm): | 4'11" (1500) |
Hydraulics
| Hydraulics | |
|---|---|
| Pump Capacity (GPM): | 8.3 (31.5) × 2 / 4.7 (18) × 1 |
| Auxiliary Hydraulic Flow (GPM): | 13.1 (49.5) |
| Max. Breakout Force (lbs): | 6924 (3140.7) / 3484 (1580.6) |
Drive System
| Drive System | |
|---|---|
| Travel Speed (low/high) | 1.7 (2.7) / 2.7 (4.3) |
| Tumbler Distance ft. in. (mm) | 5'1.4" (1560) |
| Crawler Length ft. in. (mm): | 6'5.9" (1980) |
