#1 Selling Compact Tractor in the USA*
BX Series is the #1 selling sub-compact tractor in the U.S. for over ten years. It gives you the best in class when it comes to reliability, comfort, and versatility.
*Based on EDA/UCC Data from 01/01/2018 - 12/31/2022 for sales of new compact tractors 0-200 Hp in the USA.
With a Kubota manufactured 3-cylinder diesel engine, HST transmission, all metal hood, fenders and chassis, the BX Series is Kubota engineered from front to rear making this a very reliable sub-compact tractor.
For a sub-compact tractor, the BX Series comfort is unmatched. With a flat operating station, tilt steering, ergonomic placement of levers and a deluxe seat, the BX Series prevents operator fatigue when working long hours on gardening, landscaping and property maintenance.
- Easy-to-Use Controls – Simple controls that are easy to understand and operate, even for first time operators.
- 3-Range Hydrostat (HST) Transmission – With an easy-to-use HST paired up with a Kubota 3-range transmission, you’re sure to find the right balance of speed and torque to get your job done quickly and efficiently.
- Kubota Treadle Pedal Design – Effortlessly change speed and direction using Kubota’s forward and reverse treadle pedals.
- Cruise Control – Allows the operator to maintain a constant speed without keeping their foot on the HST pedal.
- Standard Rear and Mid PTO – Easily set your settings to use front, mid, or rear implements.
Kubota’s versatile multi-purpose tractor offers four affordable models ranging from 16.6 to 24.8 HP to help you achieve your everyday tasks. This sub-compact tractor comes with an assortment of Performance Matched Land Pride implements such as a box blade, quick hitch, and pallet fork just to name a few. The BX Series line up also offers the BX23S, a dedicated TLB to help you with all your digging jobs.
| Engine | |
|---|---|
| Model: | Kubota D902 |
| Engine Gross HP at 3200 RPM: | 21.6 |
| PTO Horsepower at 3200 RPM: | 17.7 |
| Displacement: | 54.8 |
| Fuel Tank Capacity: | 6.6 gal |
| Drive Train | |
|---|---|
| Transmission: | HST, High-Low gear shift (2 forward/reverse) |
| Drive Method: | 4WD |
| Brakes: | Wet Disc |
| PTO: | Live Independent PTO (with hydraulic clutch) |
| Hydraulics | |
|---|---|
| Pump Output: | 6.2 gpm |
| 3-Point Hitch: | Optional |
| Lift Capcity at 24 in. Behind Pin: | 680 lbs |
| Steering: | Hydroslatic Power Steering |
| Dimensions | |
|---|---|
| Wheelbase: | 55.1 in. |
| Turning Radius (w/o brake): | 7.5 ft. |
| Tractor Weight with ROPS: | 1600 lbs |
| Traveling Speeds at Rated Engine RPM | |
|---|---|
| Forward: | 0-8.4 mph |
| Reverse: | 0-6.5 mph |
